| 型號 model | ZJ-UB-1903D-DK-WB5 |
| 搭載機頭 Carrying nose | ZJ1903D-3/04-74 |
| 最高縫制速度 Maximum sewing speed | 2700sti/min |
| 紐扣間隔 Button spacing | 任意設定:全長<655mm Arbitrary setting:totallength ≤ 655mm |
| 紐扣與縫料邊緣間隔 Button and seam edge spacing | 9-21mm |
| 使用紐扣種類Types of buttons used |
圓形平紐扣標準:四眼;二眼(可選三眼;五眼) Round flat button standard: four eyes;Two eyes (optional three eyes; five eyes) |
| 使用針 Using needles | DPX17 |
| 紐扣直徑 Button diameter | Φ9~Φ20 |
| 紐扣厚度 Button thickness | 1.8-4mm |
| 最大縫料輸送距離 Maximum seam material conveying distance | <650mm |
| 上端間隔 Upper interval | <50mm |
| 標準紐扣縫制形狀 Standard button sewing shape | 50個 |
| 紐扣縫制設定范圍 Button sewing setting range | 2-20個 |
| 電壓 voltage | 220V |
| 氣壓、空氣消費量Air pressure,air consumption | 0.5MPa 1.8 1/min |
| 機器重量(凈重)Machine weight(net weight) | 322KG |
| 機器重量(毛重)Machine weight (gross weight) | 414KG |
| 機器尺寸(長X寬X高)Machine size (length xwidth xheight) | 2220X1120X1430mm |
| 包裝尺寸(長X寬X高) Packaging size (length xwidth xheight) | 2300X1420X1500mm |
