| 機器型號 Machine model | ZJ-UA-5781D-SY-NB5 |
| 搭載機頭 Carrying nose | ZJ5781DS-V3 |
| 最高縫制速度 Maximum sewing speed | 4200sti/min |
| 鈕孔長度 Button hole length | ≤25 |
| 切刀尺寸 Knife size | 6.4-19.1(1/4-3/4)mm |
| 壓腳提升高度 Presser foot lifting height | ≤14mm |
| 使用針 Using needles | DPX5 |
| 鈕孔間隔 Buttonhole spacing | ≤610mm |
| 鈕孔與縫料邊緣間隔 Spacing between button hole and seam edge | 7-21mm |
| 最大縫料輸送距離 Maximum seam material conveying distance | ≤610mm |
| 上端間隔 Upper interval | ≤140mm |
| 縫料寬幅 Wide width | 220-420mm |
| 縫料長度 length of seam material | 480-880mm |
| 電壓 voltage | 220V |
| 氣壓、空氣消費量Air pressure,air consumption | 0.5MPa 1.8 1/min |
| 機器重量(凈重)Machine weight(net weight) | 353KG |
| 機器重量(毛重)Machine weight (gross weight) | 483KG |
| 機器尺寸(長X寬X高)Machine size (length xwidth xheight) | 2220X1070X1500mm |
| 包裝尺寸(長X寬X高) Packaging size (length xwidth xheight) | 2300X1100X1530mm |
